Sensors & Accessories
From sensor tip to DAQ input — every link in the measurement chain.
- ●TACPB-10T3: uniaxial MEMS IEPE accelerometer, plug-and-measure with PhonoVibe
- ●Third-party accelerometers in stock: industrial, compact, and low-frequency variants
- ●ICP® electret array microphone for sound level and acoustic measurements
- ●Low-noise coaxial and armored accelerometer cables in 5 m standard length
- ●SS304 triaxial mounting block and magnetic mount for rapid sensor fixture
- ●Adhesive pad set for non-magnetic surfaces
| SKU | Model | Price (INR) | Price (USD) | Notes |
|---|---|---|---|---|
| TACPB-10T3 | TACPB-10T3 — Uniaxial MEMS IEPE Accelerometer | — | — | Price on request |
| 151A500D | 151A500D — 500 mV/g Industrial Accelerometer | ₹24,522 | — | |
| AC192-1D | AC 192-1D — Compact Multipurpose Accelerometer | ₹16,280 | — | |
| AC102-1D | AC102-1D — Multipurpose Accelerometer | ₹15,000 | — | |
| AC153-1D | AC153-1D — Low Frequency Accelerometer | ₹34,900 | — | |
| 130F20 | 130F20 — ICP® Electret Array Microphone | ₹57,600 | — | |
| CA-101-5-M-B | CA-101-5-M-B — Low-Noise Coaxial Cable, 10-32 to BNC, 5 m | ₹2,200 | — | |
| CA-102-5-D-B | CA-102-5-D-B — 2-Core Twisted Shielded Cable, MIL to BNC, 5 m | ₹1,500 | — | |
| CA-103-5-A | CA-103-5-A — Armored SS Outer Cable, MIL to Bare/BNC, 5 m | ₹2,300 | — | |
| CA-103-5-RD | CA-103-5-RD — Armored SS Outer Cable, Right-Angle MIL, 5 m | ₹2,500 | — | |
| TMB-101-1-A | TMB-101-1-A — SS304 Triaxial Accelerometer Mounting Block | ₹2,500 | — | |
| TMA-101-1 | TMA-101-1 — Magnetic Accelerometer Mount | ₹1,800 | — | |
| TAP-101-1A | TAP-101-1A — Adhesive Pad Set | — | — | Price on request |
Sensors and cables are the first points where measurement quality is either protected or lost. TIERA stocks a range of IEPE accelerometers covering the most common field requirements: general-purpose, compact for tight spaces, low-frequency for slow machinery (pumps, fans, gearboxes below 10 Hz), and high-sensitivity industrial-grade units. The 130F20 ICP® electret array microphone extends the system into acoustic measurements — sound level, octave-band analysis, and spatial mapping when combined with PhonoVibe multi-channel DAQ systems.
All cables in the TIERA accessory range are designed for industrial environments. Low-noise coaxial construction (CA-101) minimises triboelectric noise — the spurious signal that appears when cable jacket flexes under vibration. Armored stainless-steel outer cables (CA-103) suit installations near moving machinery where cable damage is a risk. Mounting accessories include a solid SS304 triaxial block for permanent installations and a quick-release magnetic mount for walk-around route-based data collection.
Individual datasheets for cables and mounts are available in the public TIERA datasheets repository:
