PhonoVibe Series

The PhonoVibe series is TIERA’s USB DAQ line for sound and vibration measurement. Four production models (D, Q, O, HD) and one integrated bench variant (Eco X) cover two-channel field kits through 16-channel modal labs.

Model lineup

Model	Channels	Sampling	Bandwidth	Input	Price (ex-GST)
PhonoVibe D	2 (BNC)	48 kHz	2 Hz – 20 kHz	±10 V	Rs 1,36,080
PhonoVibe Q	4 (BNC)	128 kHz	0.5 Hz – 60 kHz	±5 V	Rs 2,88,000
PhonoVibe O	8 (BNC)	128 kHz	0.5 Hz – 60 kHz	±5 V	Rs 4,60,800
PhonoVibe HD	16 (BNC)	128 kHz	0.5 Hz – 60 kHz	±5 V	Rs 7,20,000
PhonoVibe Eco X	4 + 20 N shaker	48 kHz	2 Hz – 20 kHz	±10 V	from $1,500

Every model: 24-bit ADC · simultaneous sampling · IEPE / ICP / CCLD sensor power (24 V / 4 mA) · TEDS support · static (DC) measurements · USB bus-powered, plug-and-play on Windows 10 and 11.

Datasheets

Individual datasheets for each model:

• PhonoVibe HD (16-ch) — Datasheet PDF
• PhonoVibe O (8-ch) — Datasheet PDF
• PhonoVibe Q (4-ch) — Datasheet PDF
• PhonoVibe D (2-ch) — Datasheet PDF

PhonoVibe Eco X — the integrated bench

The Eco X is a complete sound-and-vibration bench in a single box: 4-channel DAQ, 20 N electrodynamic shaker, 150 W amplifier, PC-based signal generator (sine, chirp, burst, random), and a sensor starter pack (100 mV/g accelerometer + 25 mV/N impact hammer). Optional MODALVIEW software for ODS and EMA.

Useful for universities running modal-analysis courses, TCAT training centres, and reliability teams needing a portable demo rig. Starts from $1,500 for the DAQ + shaker unit, or $6,750 for the full kitted bundle including TVIB and sensors.

What ships in the box

Every PhonoVibe DAQ ships with:

• TVIB TSAP 201 software (perpetual licence — ~Rs 37,000 standalone value)
• Connectors and cables for sensor wiring
• USB cable, quick-start guide
• Factory calibration certificate (1-year validity)
• 2-year standard warranty (extendable to 3 with AMC)

Choosing a model

• PhonoVibe D — single-machine condition monitoring, classroom teaching, field service kit.
• PhonoVibe Q — small reliability team, multi-bearing or shaft-end measurement, mid-range modal work.
• PhonoVibe O / HD — full modal testing, line-monitoring banks, multi-axis transducer arrays, R&D labs requiring parallel multi-channel capture.
• PhonoVibe Eco X — universities, training centres, and engineering colleges that need a self-contained signal-chain bench.

What pairs naturally

• TVIB TSAP 201 (bundled free) for time waveform, spectrum, FRF, octave, balancing
• TMFSS as a controlled-fault source for training and algorithm validation
• TIERA accelerometers (TACPB-10T3 MEMS) and cables — see Sensors & Accessories — or bring your own IEPE sensors

Third-party DAQ compatibility

TVIB also supports National Instruments 9234 / 4431, Modal Shop 485B39, Sinus Apollo Light, and Data Translation DT9837 — useful if you’re integrating PhonoVibe into a mixed-DAQ lab.

Pricing excludes GST. Academic discount of 10–15% is available on hardware — confirm with sales.
